GS-750BD
Laptop polishing equipment
Model features
1. The four sided polishing head can be configured with different styles of consumables, which can achieve various appearance requirements;
2. Multiple products are polished simultaneously, resulting in high efficiency;
3. It can rotate at any angle and polish inclined surfaces at different angles;
4. The spacing size is 450mm, which can polish note products under 17.3 inches at the same time.
5. Automatic replacement of consumables greatly increases production efficiency, using CNC system with five axis linkage
Basic parameters of machine tool
Model content | Parameter |
Function | Grinding and polishing |
Quantity of workpieces processed at once | four |
Continuously complete the process | 4 lanes |
A-axis rotation angle | -5°~+365° |
X/Y/Z axis travel (mm) | X:480 Y:400 Z:300 |
X/Y/Z axis repeat positioning accuracy (mm) | ±0.02 |
C-axis swing angle | 360 degree continuous (-5 °~+365 °) |
Voltage | AC 380V |
Total power | 9KW |
Air pressure | ≥0.5Mpa |
Water | recycle |
Dimensions (length * width * height mm) | 2440X1980X2250 |
Applicable to products | Laptop products |
Processing product dimensions | Below 17.3 inches |
XYZ feed rate | 100-500mm per second |
control system | New generation system |
Motor model | 1.7KW/RT28 1.7KW/RT29 3.1KW/RT21 |
Japan Kamo Roller | CPA1610B-2B |
Japan Kamo Gear | CRA1610A-2BF-L992 |
Electric spindle grinding head speed | 300-6000 |
Equipment weight | 3000KG |
